CIOKS C1 CRUX

CIOKS CRUX is the ultimate add-on to CIOKS DC7 if you are using a Neural DSP Quad Cortex, a Line 6 HX- series pedal or another power-hungry 9V or 12V multi-effects pedal.  Simply connect the CRUX to the 24V outlet on DC7, set the correct voltage on CRUX, connect the appropriate CIOKS Flex cable from CRUX to your multi-effect pedal and you are good to go.

Using CRUX frees up the outlets on DC7 that would otherwise be needed to run these devices (for instance four for a Neural DSP Quad Cortex and two outlets for a Line HX Stomp), allowing you to run more pedals along with your multi-effects device. CRUX therefore provides a simpler, more reliable setup and gives you more options for connecting additional pedals.

Note: Meant to work seamlessly with the DC7.  It can be used with SOL and Hi5 MOD, but it requires numerous extra adapter cables and will take up 4 of your supply outlets.

FEATURES

    Converts the 24V aux outlet on DC7 into a powerful 9 or 12V outlet with a total power of 24W
    Powers a Neural DSP Quad Cortex with DC7 saving you 4 outlets on the DC7
    Overload and short circuit protected outlet
    Overvoltage protected outlet protecting your equipment
    CIOKS CRUX has the same 1-inch profile (25,4mm) as CIOKS DC7
    Compatible with CIOKS MiniGRIP for drill-free mounting underneath Pedaltrain boards (sold separately)
    One 24V DC Link cable included
    Two Flex cables included
    Designed in Denmark, assembled in Poland
    5-year worldwide warranty
SPECIFICATIONS

Input: 24V DC
Output: 9V DC / 2700 mA or 12V DC /2000 mA
Total output power: max. 24W
Cables included:
1x Flex 1050 – Type 1 - 5,5/2,1mm DC-plug, centre negative, L-shape, 30cm (black)
1 x Flex 3050 - Type 3 - 5,5/2,5mm DC plug, centre negative, L-shape, 50cm (yellow)
1 x L2415 DC Link cable - EIAJ to EIAJ, 15cm (black)
INCLUDES

CRUX adapter
L2415 DC Link cable
2x Flex cables, #1050 and #3050
Mounting hardware for Pedaltrain and Templeaudio boards
Product manual
Flex Guide
CIOKS sticker sheet
Fun notes: "CIOKS is rooted in a danish word Tjåks.  There isn't really an equivalent pronunciation in English.  It's somewhere in between 'checks' and 'chucks' (like Chuck Norris).  Something like 'chiucks', if that were a word.  They recommend people just say 'Chucks", probably because we English speakers generally kinda suck at pronouncing non-English words. However, most people in North America pronounce it CHOCKS. ;)"

Model:	CIOKS-C1
Manufacturer:	CIOKS
