CIOKS DC7 Power Supply
Description
The groundbreaking DC7 has a one inch profile and weighs 1.1 pounds thanks to the pure 2-stage switch-mode technology inside.
The profile may be low but the power ratings certainly aren't: the DC7 puts out a maximum of 48W from its 9 outlets.
The DC7 lets you connect multiple high-current effects from manufacturers like Effectrode and Eventide without noise of any kind.
CIOKS DC7 features 7 isolated DC outlets with four selectable voltages.
Each of the outlets can put out 660mA of current at 9V.
Additionally the DC7 has a 5V USB outlet and an auxiliary 24V outlet.
The DC7 is expandable with compatible 24V DC power supplies for even more isolated outlets and even more flexibility.
Combine the DC7 with the Flex cables included and you have one of the most flexible, noise-free solutions on the market for powering large pedalboards!
CIOKS DC7 Power Supply features:
• 7 isolated DC outlets.
• 660mA at 9V DC on each outlet.
• 4 selectable voltages on each outlet (9V, 12V, 15V or 18V DC).
• 5V USB outlet (1000mA).
• 24V DC auxiliary outlet (2000mA).
CIOKS DC7 specifications:
• Groundbreaking 1-inch profile (25.4mm).
• 2-stage switch-mode power supply topology.
• Ultra-low noise achieved by multistage filtering.
• Individual power limit LED on all outputs.
• Built-in true power meter showing the total load.
• Global overload status LED.
• Universal mains input voltage: 90 to 265V AC.
• Total maximum output power: 48W.
• Compatible with CIOKS GRIP for drill-free mounting on Pedaltrain boards.
• Expandable with CIOKS 4, CIOKS 8 or other compatible units with 24V input voltage for additional isolated outputs.
• Weighs 1.1 lbs (500 grams).
CIOKS DC7 includes :
• 12 Flex cables.
• Mounting hardware for Pedaltrain and Temple Audio pedalboards.
• Power cord.
Note:
• U.S. customers will receive a North American power cord.
• European customers will receive an European power cord.
• United Kingdom customers will receive a UK power cord.
• Australia and New Zealand customers will receive an Australian power cord.
Model: | CIOKS-DC7 |
Manufacturer: | CIOKS |
