Radial OX8-R (Eclipse transformer) 8-channel Microphone Splitter
Rackmount Mic-Level Passive Splitter
The OX8™ is an eight channel passive mic splitter designed to send the outputs of multiple microphones to three destinations at once, with transformer isolation and ground lifts to eliminate hum and buzz from ground loops.
Noise-free microphone splitting
The Radial OX8 is a professional audio tool that is equally at home on a live stage as it is in a broadcast studio, splitting eight microphone signals to multiple destinations simultaneously without noise or distortion, and eliminating hum and buzz from ground loops. Each channel is configured with a balanced input, a direct out which also serves as a return path for 48V phantom power, a thru-put with a ground lift switch, and a fully transformer-isolated output. The OX8 may be ordered with premium Jensen JT-MB-CPC transformers or Eclipse ET-MS10 transformers as an affordable alternative. Each channel also benefits from an ultra-short signal path and built in RF filters to ensure absolute quiet performance even in the most noise-prone environments.
Features:
- Balanced 8-channel microphone signal splitter
- Delivers high quality audio without distortion
- Choice of Eclipse or premium Jensen transformers
- Eliminates hum and buzz caused by ground loops
Model: | R800800300 |
Manufacturer: | Radial |
